GD&T Symbols With Examples (Geometric Dimensioning and Tolerancing)

Geometric Dimensioning and Tolerancing (GD&T) defines how parts must fit, seal, locate, and rotate—not just what size they are. When done right, GD&T replaces ambiguous dimensions with functional rules that manufacturing and inspection can actually prove.

If you’ve ever asked why a part is “in size” but still doesn’t assemble, GD&T is the answer.

I teach GD&T the way it’s learned on the shop floor: clear rules, tight sketches, and decisions tied directly to function. This guide is a practical reference for students and practicing engineers who want to know what to use, why to use it, and how to apply it today.

What GD&T Symbols Do — and Why They Matter

GD&T controls:

• Form (shape)

• Orientation

• Location

• Runout

A good GD&T callout tells the shop how the part must behave in assembly, not just its dimensions. Correct GD&T:

• Reduces rework

• Shortens inspection time

• Removes interpretation errors

• Allows functional verification, not guesswork

Before adding any symbol, ask one question:

Which assembly or performance requirement fails if this feature is wrong?

That answer determines the symbol.

• ⌀ Diameter — Cylindrical features such as holes and shafts

• ⌖ Datum — Functional reference for location and orientation

• Position (⦿) — Bolt patterns, dowel holes, locating features

• Flatness — Mounting and sealing faces

• Profile — Complex or sculpted surfaces

• Circularity — Bearing journals and rotating fits

• Runout / Total Runout — Rotating balance and stability

How to Choose the Right GD&T Symbol (Functional Rule)

Choose the control that directly prevents failure:

• Feature must locate → Position

• Surface must mate or seal → Flatness or Profile

• Part must rotate smoothly → Circularity or Runout

This rule beats memorizing symbol definitions.

Practical Examples (Short Case Studies)

1. Flange Bolt Pattern — Position

Bolt holes drifted after welding.
Solution: Position tolerance to:

• Datum A (mating face)

• Datum B (centerline)

• With MMC

Result: Bonus tolerance during manufacturing, guaranteed assembly fit, zero rework.

2. Motor Mounting Face — Flatness

Motors tilted and required shims.
Solution: Single Flatness callout on the machined face.

Result: One-setup machining, shims eliminated.

3. High-Speed Shaft — Circularity + Runout

Bearing failures due to out-of-round journals.
Solution: Circularity on journals + Runout relative to shaft datum.

Result: Lower vibration, longer bearing life.

GD&T vs Tolerance Stack-Up

When assembly performance depends on geometry, replace chains of linear dimensions with geometric controls.

• Linear stacks → worst-case accumulation

• Position/Profile → functional tolerance zones

A quick stack-up check tells you whether size or geometry should control the feature.

Practical Comparison

Teach-a-Junior Checklist

• Identify the function: locate, seal, or rotate

• Pick the primary datum where the part actually mates

• Use Position + MMC for bolt patterns

• Use Flatness to eliminate shimming

• Use Profile for complex sealing geometry

• Link each callout to how it will be measured

• Avoid redundant dimensions that fight GD&T

• Add a short inspection note on the drawing

Measurement Mapping (Design → Inspection)

Every GD&T callout should include one inspection method:

• Position → CMM, datum-based measurement, MMC virtual condition

• Profile → CMM scan strategy with allowable deviation

• Circularity/Runout → Dial indicator or CMM rotary routine

This keeps design, manufacturing, and inspection aligned.

How to Add GD&T to a Production Drawing (Step-by-Step)

1. Identify the functional requirement

2. Select real assembly contact surfaces as datums

3. Choose the symbol that prevents the failure mode

4. Add MMC/LMC only when it adds value

5. Specify the inspection method

6. Avoid unnecessary stacked dimensions

Process-Aware Tolerancing

• Match tolerance to machine capability

• Check fixturing before tightening form controls

• For sheet metal, plan bends and fixtures before Profile

• For motion systems, account for bearing preload and alignment

Welding & Fixtures — Control Early

Welding distorts geometry.
Control it with:

• Symmetric weld sequences

• Datum-locking fixtures

• Controlled tack strategy

Good fixturing reduces the need for tight post-weld tolerances.

Two Questions Before Release

1. Can this be measured easily and repeatedly?
   If not, revise the callout or add a functional gauge.

2. Does this guarantee assembly without shimming or forcing?
   If not, reconsider MMC or the chosen control.

One Change to Make Today

On your next drawing:

• Find one recurring assembly problem

• Replace stacked dimensions with one clear GD&T callout

• Add a small sketch and inspection note

Do it on one part. Track first-article results.

Conclusion

GD&T symbols with examples turn drawings from instructions into proof of function. Small, deliberate callouts—paired with a clear inspection plan—cut rework, speed launches, and lower cost.

GaugeHow provides workshop-ready GD&T guides, diagrams, and downloadable templates to train teams faster.
Download the PDF and standardize your drawings today.

FAQs

1. Most used GD&T symbols?
Datum, Position, Flatness, Profile, Circularity, Runout.

2. Why use MMC with Position?
It guarantees assembly while allowing bonus manufacturing tolerance.

3. Can a CMM measure all GD&T?
Most, yes—if the measurement strategy is specified.

4. Profile vs linear dimensions?
Use Profile when surface geometry affects function as a whole.

5. How to keep GD&T shop-friendly?
Functional datums, simple sketches, clear inspection notes.

6. Can GD&T reduce cost?
Yes. Proper GD&T reduces scrap, rework, and inspection time.
